Autoclave Vertical

Get a Price/Quote

Autoclave Vertical Specification

Model No
AVCL-22L

Measurement Range
0-2.5 bar

Core Components
Pressure Gauge, Safety Valve, Heating Element

Power Source
Electric

Temperature Range
Up to 134C

Feature
Double Safety Lock, Auto Pressure Release

Accuracy
1C

Automation Grade
Semi-Automatic

Frequency
50 Hz

Voltage
220 V AC

Capacity
22 Liters

Equipment Materials
Stainless Steel (Inner Chamber & Lid), Outer Mild Steel (Powder Coated)

Type
Vertical Autoclave

Usage
Laboratory Sterilization

Display Type
Analog Pressure Gauge

Dimension (L*W*H)
400 x 400 x 700 mm

Weight
Approx. 45 kg

Heater Power Consumption
2 kW

Chamber Depth
400 mm

Heating Method
Immersion Heater

Working Pressure
1.2-1.5 kg/cm2 (15-21 psi)

Construction Standard
ISI Marked/Certified as per IS:3829

Chamber Diameter
300 mm

Number of Baskets
1 Stainless Steel Perforated Basket

Water Level Indication
Provided

Lid Type
Radial Locking Lid with Pressure Seal

Safety Features
Pressure Release Valve, Gasket Release System

Sterilization Cycle Duration
15-30 minutes

About Autoclave Vertical

Autoclave vertical

A versatile, electrically heated sterilizer under saturated steam of Adjustable pressure of 10 to 20 psi. double walled construction with boiler & steam jacket made of thick stainless steel and gap is filled with high grade glass wool to bring the temp. loss to a minimal level.The outer chamber is made out of thick mild steel.The lid is made of thick stainless steel plate (joint less) or gunmetal plate and can be sealed by a jointless neoprene rubber gasket by wing nuts through hinged bolts by engaging slotted lugs on rim of the cover. Provided with dial pressure gauge, air/ steam release cock, spring loaded safety valve adjustable to any required point from 10 psi to 20 psi with accuracy + 3 psi. A drain cock has also been provided. A double safety valve has also been provided along with inlet. Supplied complete but without dressing bins.

Chamber Size & load Capacity (approx.)

Dia x Depth

250x450mm 2KW 22ltrs.
300x500mm 3KW 40ltrs.
350x550mm 4KW 50ltrs.
400x600mm 5KW 78ltrs.
450x600mm 5kW 98ltrs
550x750mm 6kW 152ltrs.

Optional:-

i) Automatic low-water level cut off- device.

ii) pressure Control switch.

iii) Water lever arrangement.

iv) Dressing bins for various size.

Robust Sterilization Performance

The AVCL-22L vertical autoclave leverages precision engineering and ISI-certified standards, making it a dependable solution for laboratory sterilization. Its chamber accommodates a variety of tools, while working pressure and cycle durations provide flexibility for different sterilization needs. Digital controls and robust safety mechanisms ensure optimum results and user assurance during every use.

Comprehensive Safety Measures

With a double safety lock, pressure release valve, and gasket release system, this autoclave puts operator safety at the forefront. The radial locking lid with a pressure seal helps maintain security under high pressure, while the analog pressure gauge and water level indicator facilitate easy monitoring. These features protect both equipment and personnel while maintaining compliance with laboratory safety protocols.

FAQs of Autoclave Vertical:

Q: How does the AVCL-22L vertical autoclave ensure effective sterilization?

A: The AVCL-22L utilizes a stainless steel chamber, immersion heater, and controlled pressure/temperature (up to 134C at 1.2-1.5 kg/cm) to achieve thorough sterilization. The cycle duration ranges from 15 to 30 minutes, allowing sterilization of various laboratory items with consistent results.

Q: What safety features are included in this autoclave model?

A: This autoclave is equipped with a pressure release valve, double safety lock, gasket release system, radial locking lid with pressure seal, and a water level indicator. These elements collectively minimize risks associated with pressure and heat during operation.

Q: When is this autoclave typically used in laboratories?

A: The AVCL-22L is used for sterilizing laboratory glassware, instruments, and other items that require aseptic handling. Its versatile cycle settings and reliable construction support routine and specialized sterilization tasks in diagnostic, research, and medical laboratories.

Q: Where is the AVCL-22L autoclave manufactured and supplied?

A: This model is manufactured, exported, and supplied by certified distributors and traders across India, ensuring availability for institutions seeking quality equipment compliant with IS:3829 standards.

Q: What is the process for operating the vertical autoclave?

A: Operation involves adding water, positioning the material in the stainless steel perforated basket, securing the radial locking lid, setting cycle parameters, and activating the immersion heater. The analog pressure gauge aids in monitoring, while automatic pressure release enhances safety during and after the cycle.

Q: What are the benefits of using a vertical autoclave with this specification?

A: Users benefit from fast, efficient sterilization cycles, robust safety features, reliable ISI-certified construction, and precision controls. The spacious chamber and accurate temperature/pressure control improve workflow and instrument safety for laboratories.

Q: How is the water level managed during operation?

A: A built-in water level indicator enables operators to monitor and maintain the appropriate water level throughout the sterilization cycle, preventing dry heating and ensuring operational safety.
