Bod Incubator

Get a Price/Quote

Bod Incubator Specification

Temperature Range
5C to 60C

Power Source
Electric

Model No
BIC-01

Feature
Double Walled Construction, Transparent Viewing Window, Adjustable Shelves, Castor Wheels for Mobility

Voltage
220-240 V AC

Capacity
112 L

Core Components
Compressor, Heater, Temperature Sensor

Automation Grade
Semi-Automatic

Accuracy
0.5C

Frequency
50 Hz

Measurement Range
0-60C

Equipment Materials
Powder Coated Mild Steel / Stainless Steel

Type
Laboratory Incubator

Usage
BOD Testing, Laboratory Applications

Display Type
Digital

Dimension (L*W*H)
450 x 450 x 900 mm

Weight
50 kg (Approx.)

Cooling System
Hermetically Sealed Compressor

Shelf Load Capacity
Up to 20 kg per shelf

Lighting
Internal Illumination

Safety Devices
Over Temperature Protection, Door Lock

Interior Material
Stainless Steel 304

Heat Up Time
Within 30 Minutes

Mounting Type
Floor Standing

Humidity Control
Optional

Number of Shelves
2-3 Adjustable Shelves

Exterior Material
Mild Steel Powder Coated

Insulation
Polyurethane Foam

Door Type
Front Opening with Glass Window

Refrigerant
CFC-free

About Bod Incubator

We offer cat bod incubator that are available in different standard sizes and wide temperature range. bod incubator is mostly used for drying; antibody & other bacteriological tests, crystallization & hydroxy steroid incubation studies, paraffin embedding, slide staining and other microbiological tests at constant temperatures. The used categories include chemicals & bio-chemicals, pollution control & monitoring, research & development and quality control labs, pharmaceutical laboratories, microbiological & biotechnology labs, college & classrooms.

Superior Construction & Materials

Constructed with a stainless steel 304 internal chamber and powder-coated mild steel exterior, the incubator ensures resistance to corrosion, easy cleaning, and long-term durability. Double-walled insulation with polyurethane foam minimizes heat loss and enhances energy efficiency, making it ideal for rugged lab use.

Versatile and Adjustable Features

This model includes 2 to 3 adjustable shelves to accommodate varying sample sizes and requirements, supporting up to 20 kg per shelf. The glass window allows for clear internal visibility without disturbing the internal atmosphere, while castor wheels add mobility for ease of use within laboratory settings.

Reliable Performance & Safety

With a temperature range of 5C to 60C, 0.5C accuracy, and rapid heat-up time within 30 minutes, the BIC-01 provides dependable environmental conditions. Advanced safety features, including over-temperature protection and door lock, safeguard your samples and experiments at all times.

FAQs of Bod Incubator:

Q: How is temperature controlled and monitored within the BIC-01 BOD Incubator?

A: Temperature is digitally controlled and displayed, allowing for precise adjustment within a range of 5C to 60C. The incubator uses a hermetically sealed compressor and a reliable heater, supported by an accurate temperature sensor, ensuring even and consistent thermal conditions with an accuracy of 0.5C.

Q: What are the benefits of the stainless steel interior and powder-coated mild steel exterior?

A: The stainless steel 304 interior is corrosion-resistant, easy to clean, and hygienic, reducing contamination risks. The powder-coated mild steel exterior adds durability and aesthetic appeal, ensuring the equipment stands up well to regular laboratory use and harsh conditions.

Q: When should the BIC-01 BOD Incubator be used in laboratory settings?

A: This incubator is ideal for use in laboratory applications requiring controlled temperature environments, such as BOD testing, microbial culturing, and incubation of biological samples. It is especially suited for regular testing where precise environmental control is critical.

Q: Where can the BIC-01 be installed or set up within the laboratory?

A: Designed as a floor-standing model with castor wheels, the BIC-01 can be easily moved and situated wherever stable, level flooring is available in laboratories, research centers, or educational institutions.

Q: What processes can be performed using the BIC-01 BOD Incubator?

A: The incubator supports processes such as BOD (Biological Oxygen Demand) analysis, microbial growth studies, tissue culture incubation, and other temperature-sensitive laboratory protocols requiring stable conditions and controlled humidity (optional feature).

Q: How does the internal illumination and glass window enhance the usage of the incubator?

A: Internal illumination combined with a front glass window allows users to easily observe internal conditions and sample status without opening the door, maintaining environmental stability and reducing the risk of temperature fluctuations.

Q: What safety features are incorporated in the BIC-01?

A: The incubator includes over-temperature protection, a secure door lock, and double-walled construction to ensure user and sample safety. These features minimize risks during critical experiments.
