Constant Spring

Get a Price/Quote

Constant Spring Specification

Core Components
Spring Coil, Load Plate, Housing

Capacity
100 Kg to 50000 Kg

Automation Grade
Manual

Accuracy
+/- 5%

Power Source
Manual/Mechanical

Measurement Range
100 Kg to 50000 Kg

Temperature Range
-10C to 200C

Model No
CS-100 to CS-50000

Feature
Corrosion Resistant, High Durability

Equipment Materials
Carbon Steel, Alloy Steel

Type
Constant Spring Support

Usage
Pipe Support, Industrial Applications

Display Type
Analog

Dimension (L*W*H)
Customized as per requirement

Weight
Varies as per model, approx. 10 to 60 kg

Standards Followed
MSS-SP-58, ANSI

Design Life
More than 10 years

Surface Finish
Epoxy Painted or Hot Dip Galvanized

Operating Medium
Mechanical

Test Pressure
1.5 times rated load

Mounting Type
Horizontal/Vertical

Packaging Type
Wooden Crate/Carton

Spring Travel
Up to 250 mm

About Constant Spring

KFW K. Constant Spring Al. Pipe 1" x 36" :

Consist with spiral spring.
one vertical meter scale
A spring hanging with a weight,
Fitted on a heavy Cast Iron Base. (1" Aluminium Pipe)

KFW -P81A K. Constant Spring Simple 1" x 24": Consist with spiral spring.

One vertical meter scale
A spring hanging with a weight,
Fitted on a heavy Cast Iron Base. (1" Aluminium Pipe)

Engineered for Longevity and Performance

Each Constant Spring Support is meticulously crafted from carbon or alloy steel, offering exceptional strength and corrosion resistance. With options for epoxy painting or hot dip galvanization, these supports withstand harsh industrial conditions. Compliance with MSS-SP-58 and ANSI standards ensures robust quality, while a design life exceeding 10 years speaks to their resilience and reliability in demanding settings.

Versatile Mounting and Customization

Constant Spring Supports are suitable for both horizontal and vertical mounting, allowing flexibility in installation across various pipe systems. Each support can be customized in dimensions (L*W*H) to align with specific requirements, and their modular core components-spring coil, load plate, and housing-accommodate diverse project needs.

Precision and Safety Assured

Featuring an analog display, easy manual operation, and a measurement range from 100 kg to 50,000 kg, the supports ensure accurate load management with a tolerance of +/- 5%. Rigorous testing at 1.5 times the rated load guarantees operational safety, while the mechanical design remains dependable in temperatures from -10C to 200C.
