Microprocessor Soil Analysis Kits

About Microprocessor Soil Analysis Kits

Microprocessor Soil Analysis Kits offered can deliver working in PH range of 0-14 pH, pH resolution of 0.01pH, pH accuracy of + 0.01 pH (relative) as well as automatic & manual calibration support.

PH:

Range              : 0-14 pH

Resolution         : 0.01pH

Accuracy           : + 0.01 pH ( relative)

Temp. Comp.        : Automatic with Pt100 Sensor

Buffer Recognition : 4.00 , 7.00 , 9.20 ( Automatic)

Calibration        : Automatic & Manual

Dissolved  Oxygen:



Range               : 0 to 20 ppm

Resolution          : 0. 1 ppm

Calibration         :  Automatic

Accuracy            : + 0.2 ppm + 1digit

Temp. Comp.         : Automatic with Pt100 Sensor

Pressure comp.      : 0-999 mm of Hg ( Manual)

Salinity Correction : 0-20 mg/l

mv/ORP:



Range        : - 2000 to +2000 mV

Resolution   : 1 mV

Calibration  : Manual

Accuracy     : + 0.1% + 1digit

Temperature:



Range       : -100 to +200 degree C

Resolution  : 0.1 degree C

Accuracy    : + 0.2% + 1digit

Input       : Pt100

Calibration :  Manual



Conductivity:



Range              : 0-200.0 mS/cm

Range Selection    : Automatic

Resolution         : 0.01 uS/cm

Accuracy           : + 0.5%

Temp. Comp.        : Automatic with Pt100 Sensor

Ref. Temp.         : 25 degree C

Temp. Co-efficient : 0-4%  adjustable

Cell constant      :  0.05 to 2.0 adjustable

TDS:



Range             : 0-200 ppt

Range Selection   : Automatic

Resolution        : 0.1 ppm

Accuracy          : + 0.5%

TDS factor        :    0.5  by default( adjustable)

Salinity:



Range           : 0-50 ppt

Resolution      : 0.1 ppt

Temp. comp.     : Automatic

Accuracy        : + 0.5%

Salinity factor :  0.75  by default( adjustable)

General Display : 16  characters X 2 linesalpha Numeric BL LCD

Display format  :  Temp. and parameter  Simultaneously

Controls        :  By soft keys Menu Driven

Storage         :  up to 1000 samples

Power supply    :   230 V +10 % 50 Hz OR 12 V   b

Option:



RS232 output available for interfacing to computer/printer

Accessories:

• pH electrode
• Two Buffer solutions
• Conductivity/TDS/Salinity Cell
• DO probe, DO membranes, KCL
• Temp. probe
• Operation manual
• ORP Electrode AT EXTRA COST

High Precision and Efficient Soil Analysis

Achieve accurate measurements of essential soil parameters including pH, EC, moisture, potassium, nitrogen, phosphorus, and organic carbon. Automated and manual calibration functions optimize accuracy, while the microprocessor controls ensure consistent results. The kit provides high throughput, capable of analyzing up to 500 samples per day, streamlining workflows for agronomists and researchers.


Durable Construction and User-Friendly Features

Built with a chemical-resistant polymer tray, stainless steel, and ABS plastic components, the kit offers durability and easy cleaning. The included glass combination pH electrode, reagent bottles, and carrying case support both field and lab use. The IP54 rating enables worry-free operation in typical agricultural environments, while the digital LCD and intuitive interface simplify operation for users of all experience levels.


Comprehensive Data Management and Connectivity

Internal memory can store up to 200 test records, ensuring data availability and traceability. Work seamlessly with any PC using the provided connectivity software, enabling effective data export through USB and RS232 ports. Laboratories and agricultural researchers benefit from secure and straightforward data handling for quality control and reporting.
