Dispensing Sampling Booth

Get a Price/Quote

Dispensing Sampling Booth Specification

Capacity
1000 CFM

Frequency
50 Hz

Power Source
Electric

Measurement Range
Airborne Particle Filtration up to 0.3 micron

Automation Grade
Semi Automatic

Accuracy
99.97% Filtration at 0.3 micron

Feature
Downflow air system, GMP Model, Low Noise Operation, Advanced HEPA Filtration

Core Components
HEPA Filter, Pre Filter, Motor Blower, Control Panel

Model No
DSB-1200

Temperature Range
5C to 50C

Voltage
230 V AC

Equipment Materials
Stainless Steel (SS 304/316)

Type
Dispensing Sampling Booth

Usage
Pharmaceutical Powders Dispensing Application

Display Type
Digital Control Panel

Dimension (L*W*H)
1200 x 900 x 2100 mm

Weight
Approx. 250 kg

Working Area Height
800 mm

Mobility
Lockable Castor Wheels

Front Panel
Polycarbonate with flexible curtains

Side Panels
Transparent Acrylic

HEPA Filter Efficiency
99.97% at 0.3 micron

Air Flow Velocity
0.45 0.05 m/s

Pre Filter Efficiency
95% down to 5 micron

Illumination Level
800 Lux

Electrical Socket Provision
Yes

Noise Level
< 65 dB

Lighting
LED Light Provided

Construction Finish
Matt Finish, Interior Corners Rounded

Blower Motor
Single Phase, TEFC, Dynamically Balanced

About Dispensing Sampling Booth

Dispensing Sampling Booth

Our vast industrial experience has enabled us to manufacture and supply a quality range of Dispensing Sampling Booth. These booths are used in medical and forensic laboratories for providing a protecting environment for the workers. To manufacture these booths we use optimum quality materials, sourced from the most reliable and trusted vendors of the market. We can make the Dispensing Sampling Booth available for the clients in different customized specifications as per requirements.

Features:

Long working life
Fire and dust proof
Compact design

Advanced Filtration and Airflow System

The Dispensing Sampling Booth is engineered with a multi-stage filtration process. A pre-filter captures particles down to 5 microns with 95% efficiency, followed by a HEPA filter providing 99.97% efficiency at 0.3 micron, ensuring a contaminant-free workspace. The downflow air system maintains consistent air velocity, safeguarding product and operator.

Optimized for Pharmaceutical Applications

Designed primarily for handling pharmaceutical powders, this booth features a spacious working area at 800 mm height and robust construction from stainless steel (SS 304/316). Transparent acrylic side panels and a polycarbonate front allow clear visibility and safe containment, meeting rigorous GMP requirements for pharmaceutical manufacturing and sampling processes.

Intuitive Digital Control and Ergonomic Design

A digital control panel displays key operational parameters, enabling precise monitoring of airflow and temperature (5C to 50C). The booth includes energy-efficient LED lighting providing 800 Lux illumination, lockable castor wheels for flexible placement, and a semi-automatic operation model for user convenience and efficiency.

FAQs of Dispensing Sampling Booth:

Q: How does the airflow system in the Dispensing Sampling Booth maintain clean working conditions?

A: The booth utilizes a downflow air system that provides consistent airflow velocity of 0.45 0.05 m/s. Pre-filters and HEPA filters work together, capturing particles down to 0.3 micron with 99.97% efficiency, ensuring that airborne contaminants are removed from the workspace during dispensing operations.

Q: What are the main benefits of using this sampling booth for pharmaceutical powder handling?

A: The booth offers advanced HEPA filtration, low noise operation (< 65 dB), high illumination ( 800 Lux), easy cleaning with rounded corners, and a GMP-compliant design. These features provide superior product, operator, and environmental protection during powder dispensing tasks.

Q: When should a pharmaceutical manufacturer use this dispensing sampling booth?

A: This booth is ideal whenever powders or fine particulates need to be dispensed or sampled in a controlled, contamination-free environment, particularly in compliance-driven GMP pharmaceutical settings where product purity and operator safety are paramount.

Q: Where can the Dispensing Sampling Booth be installed, and is it mobile?

A: It can be installed in pharmaceutical manufacturing units, laboratories, or any cleanroom facility. The booth has lockable castor wheels, allowing for easy mobility and secure placement wherever needed within the workspace.

Q: What is the process for operating the Dispensing Sampling Booth?

A: Operators activate the booth using the digital control panel, which manages airflow, filtration, and temperature settings. Materials are dispensed within the protected working area, while filters and the downflow system ensure clean air, and all processes are carried out while monitoring on-screen parameters.

Q: How is user safety ensured in this booth?

A: User safety is achieved through efficient air filtration, reduced noise exposure, LED lighting for clear visibility, transparent panels for supervision, and physical barriers formed by polycarbonate curtains, all contributing to a controlled and safe dispensing process.
