Microprocessor Based PH / Temperature / MV Meter

Get a Price/Quote

Microprocessor Based PH / Temperature / MV Meter Specification

Core Components
Microprocessor, PH Electrode, Temperature Sensor

Feature
Automatic Temperature Compensation, Data Hold, Calibration

Measurement Range
pH: 0-14, mV: ±1999mV, Temperature: 0-100°C

Accuracy
±0.01 pH, ±0.1°C

Model No
MP-101

Frequency
50 Hz

Capacity
200ml

Temperature Range
0°C to 100°C

Voltage
220 V

Automation Grade
Automatic

Power Source
AC Adapter

Equipment Materials
ABS Plastic Body

Type
PH/Temperature/MV Meter

Usage
Laboratory, Industrial Use

Display Type
Digital LCD Display

Dimension (L*W*H)
280 mm x 230 mm x 110 mm

Weight
2.5 Kg

Storage Temperature
-10C to 60C

Sampling Rate
2 samples per second

Protection Class
IP20

Resolution
0.01 pH, 1 mV, 0.1C

Calibration Method
3-Point Calibration

Power Consumption
<10W

Operating Temperature
5C to 45C

Data Output
RS232 / USB

Electrode Input
BNC

About Microprocessor Based PH / Temperature / MV Meter

We provide Microprocessor Based pH / Temperature / MV Meter with following specifications.

Specifications
Display	16 x 2 alpha numeric LCD display
Range	0 to 14 pH 0 to + 1999.9 mV, Temp. 0 to 100^oC
Resolution	.01 pH 0.1 mV Temp. 0.1 Deg. C
Accuracy	+ 0.01 pH + 1 digit mV, Temp + 0.10
Calibration	Auto / Manual
Storage	Upto 100 samples
Power	230V + 50Hz
Accessories	pH Electrode, Temperature probe, Electrode Stand, Buffer solution, Dust cover, Manual

Precision Measurement and Calibration

The MP-101 meter delivers high-precision analysis with a 0.01 pH, 1 mV, and 0.1C resolution, ensuring reliable results for critical applications. Its 3-point calibration method enhances the devices accuracy and minimizes measurement drift, providing confidence in data consistency over time. This capability makes it a top choice for laboratories and industrial environments requiring stringent quality control.

User-Friendly Data Handling and Connectivity

Equipped with a digital LCD display, the MP-101 offers clear readings and easy navigation through settings. RS232 and USB outputs enable simple data transfer and integration with computers for efficient data management and analysis. The Data Hold function allows users to pause and review measurements at any point during operation.

Robust Design for Laboratory and Industrial Use

Constructed from high-quality ABS plastic, the MP-101 is built to withstand demanding laboratory and industrial settings. With an IP20 protection class, operating temperatures from 5C to 45C, and wide storage tolerance, the meter ensures longevity and stability. Weighing 2.5 kg with a compact footprint, it is easy to install and relocate as required.

FAQs of Microprocessor Based PH / Temperature / MV Meter:

Q: How is the MP-101 Microprocessor-Based Meter calibrated?

A: The MP-101 utilizes a 3-point calibration method for pH measurement, allowing users to calibrate the meter at three different standard buffer solutions. This approach ensures superior accuracy and compensates for electrode drift, making the instrument highly reliable for diverse laboratory and industrial applications.

Q: What types of measurements can the MP-101 record and display?

A: This meter can measure and display pH (ranging from 014 pH), temperature (0C to 100C), and millivoltage (1999 mV) on its digital LCD screen, enabling comprehensive monitoring of various solutions and conditions.

Q: When and where is this meter typically used?

A: The MP-101 is ideally used in laboratory and industrial environments in India and globally, where accurate assessment and monitoring of pH, temperature, or millivoltage are criticalfor example, chemical analysis, water quality testing, and manufacturing processes.

Q: How does the automatic temperature compensation feature benefit users?

A: Automatic temperature compensation ensures that pH readings remain accurate regardless of temperature fluctuations in the sample. This feature enhances precision and reliability without requiring manual adjustments from the user.

Q: Where can measurement data be exported from the device?

A: Measurement data can be exported via the RS232 or USB outputs, facilitating seamless integration with computer systems for record keeping, analysis, or regulatory compliance.

Q: What is the process for using the MP-101?

A: To use the meter, simply connect the appropriate electrode via the BNC input, immerse it in the sample, and follow the setup instructions on the digital LCD display. After calibration, readings for pH, temperature, and mV are acquired at 2 samples per second, and can be held, viewed, or exported as needed.

Q: What are the main benefits of using this microprocessor-based meter?

A: Key advantages include high measurement accuracy (0.01 pH, 0.1C), robust automatic features like calibration and temperature compensation, user-friendly digital display, dependable connectivity options, and durable ABS construction suitable for frequent use in demanding environments.
