Optical Bench

Get a Price/Quote

Optical Bench Specification

Power Source
Not required (Manual)

Feature
Adjustable component holders, clear scale graduations, stable base

Measurement Range
Up to 1 meter

Accuracy
Graduated scale to 1 mm

Capacity
Single Observation Tube Arrangement, 1 meter

Temperature Range
Ambient only

Core Components
Bench scale, optical rider supports, component holders, leveling screws

Model No
OB-100

Automation Grade
Manual

Equipment Materials
Stainless Steel Scale with heavy cast iron base, metallic component holders

Type
Optical Bench, Physics Laboratory Instrument

Usage
Physics Laboratory Experiments, Demonstration of Optical Principles

Display Type
N/A (Manual / Non-digital)

Dimension (L*W*H)
Approx. 100 cm (L) x 7 cm (W) x 18 cm (H)

Weight
Approx. 10-12 kg

Bench Material Finish
Polished, rust-resistant

Mobility
Stationary

Instruction Manual
Included

Number of Component Carriers
3 (with locking arrangement)

Level Adjusting Screws
Provided for stable positioning

Mounting Type
Table-top

Compatible Accessories
Slit, lens holder, object & screen (not included)

Scale Graduation
1 mm interval

Assembly
Ready-to-use (no extra setup required)

Application Area
Schools, Colleges, Universities

About Optical Bench

KFW- Optical Bench

1mtr. sup.
Iron Rod
Half Shaper

KFW-P91 A Optical Bench

1.5 mtr. sup.
Iron Rod
Half Shaper

KFW-P91 B Optical Bench

1mtr. sup.
Brass Rod
full Shaper

KFW-P91 C Optical Bench

1.5mtr. sup.
Brass Rod
full Shaper

KFW-P91 D Optical Bench

1mtr. S.S Rod,
full Shaper

KFW-P91 E Optical Bench

1.5mtr. S.S. Rod
full Shaper 18mm Rod

Durable Construction for Long-lasting Use

The OB-100 Optical Bench is built with a stainless steel scale and heavy cast iron base, ensuring stability and resistance to rust in laboratory settings. The polished finish offers both aesthetic appeal and practical utility, making it suitable for repeated, long-term classroom use without the risk of deterioration.

Precise Measurements Every Time

Featuring a scale graduated in 1 mm intervals, the bench enables highly accurate setup and measurement for a wide range of optics experiments. Adjustable component holders with locking arrangements provide secure positioning, aiding students and educators in obtaining reliable results.

Simple, Ready-to-Use Setup

The OB-100 arrives fully assembled and ready for immediate use, requiring no additional setup or special tools. Its stationary, table-top design and integrated leveling screws make it easy to achieve stable, horizontal positioning on laboratory benches.

FAQ's of Optical Bench:

Q: How does the locking arrangement on the optical bench carriers improve the setup process?

A: The locking arrangement ensures each of the three component carriers stays securely in place during experiments, preventing accidental shifts. This enhances measurement accuracy and repeatability, especially when demonstrating optical principles or conducting precise laboratory investigations.

Q: What accessories are compatible with the OB-100 Optical Bench, and are they included?

A: The bench is compatible with accessories such as a slit, lens holder, object, and screen. These items are not included with the standard package and should be acquired separately as per experimental requirements.

Q: When is it necessary to use the leveling screws on the optical bench?

A: Leveling screws should be used whenever you set up the optical bench on a new surface to ensure the bench is perfectly horizontal. This prevents measurement discrepancies due to tilting and provides a reliable foundation for all experiments.

Q: Where is the OB-100 Optical Bench best suited for use?

A: This model is specifically designed for physics laboratories in educational institutes, including schools, colleges, and universities, where it supports the teaching and demonstration of key optical concepts.

Q: What is the benefit of having a stainless steel scale with 1 mm graduations on this optical bench?

A: The stainless steel scale provides long-term durability and clear visibility, while the 1 mm graduations allow for fine, precise measurements. This level of accuracy is particularly beneficial in experiments that require detailed observation of optical phenomena.

Q: How do you assemble and maintain the OB-100 Optical Bench?

A: No assembly is required; the product comes ready-to-use with an instruction manual included. Maintenance is simple-keep the surface clean and dry, and check that the leveling screws and component holders are secure before each use.

Q: What types of experiments can be conducted with this optical bench?

A: The OB-100 Optical Bench is versatile for a variety of physics experiments, particularly the demonstration and investigation of optical properties such as refraction, image formation, focal length determination, and more, making it ideal for laboratory instruction and hands-on learning.
