Expansion Of Liquids Apparatus

Get a Price/Quote

Expansion Of Liquids Apparatus Specification

Accuracy
1 mL or better (depends on thermometer and tube graduation)

Measurement Range
Liquid expansion (0-100 mL) relative to temperature change

Power Source
Not applicable (external heating required)

Automation Grade
Manual

Temperature Range
Room temperature to 100C

Model No
Standard/Custom (varies by manufacturer)

Capacity
2 75 mL (Glass Bulbs)

Core Components
Glass Bulbs, Graduated Capillary Tubes, Water Bath, Metal Stand

Feature
Simultaneous expansion measurement of two different liquids

Frequency
N/A - Not electrically powered

Equipment Materials
Glass Bulbs, Metal Stand, Graduated Tubes, Water Bath (Brass/Copper)

Type
Physics Laboratory Apparatus

Usage
Demonstration of expansion of different liquids when heated

Display Type
Graduated Glass Tubes

Dimension (L*W*H)
Approx. 40 15 20 cm

Weight
Approx. 2-5 kg (including water bath and accessories)

Application Area
Physics Education, Laboratory Experiments

Accessories Supplied
Water bath, metal stand, 2 bulbs, 2 glass tubes, thermometer

Mounting Type
Portable, Bench-top

Colour
Clear/Transparent (glass), Metallic/Polished (stand & bath)

Safety Features
Non-toxic, smooth edges, heat-resistant design

Compliance
Meets standard laboratory safety norms

Thermometer Included
Yes, typically up to 110C

Water Bath Capacity
Approx. 500-1000 mL

Number of Samples
2 (dual liquid comparison)

Heating Source Required
External heat source, e.g., Bunsen burner

Suitable Liquids
Water, alcohol, kerosene, oils etc.

About Expansion Of Liquids Apparatus

For demonstrating the different thermal expansions of various liquids.Comprising five bulb tubes mounted in a frame and supported in a water trough. The frame has a special sliding arrangement with clips hold glass bulbs with tubes. The bulbs can be easily removed and fixed and have a funnel formation on top for easy filling.

Dual-Liquid Thermal Expansion Demonstration

This apparatus enables simultaneous investigation of two different liquids, illustrating the fundamental concept of liquid expansion due to heat. With dual graduated glass tubes and bulbs, students can visually compare the behavior of substances like water and alcohol. It's perfect for demonstrations, practical classes, and experiments in physics curriculums, offering clear and accurate comparisons.

Integrated Safety and Durable Design

Constructed with quality glass, polished metal components, and non-toxic materials, the apparatus features smooth edges and heat-resistant properties. A transparent water bath made from sturdy brass/copper ensures safe and even heating. Compliant with laboratory safety norms, it provides a secure environment for both educators and students during hands-on learning.

Versatile and Portable Laboratory Solution

With a compact, bench-top design (roughly 40 x 15 x 20 cm), the apparatus is easily transported and stored. Manual operation and external heating (using standard lab equipment) make it convenient for a variety of classroom or laboratory settings. All necessary accessories are included, making it a ready-to-use solution for effective physics education.

FAQ's of Expansion Of Liquids Apparatus:

Q: How does the Expansion Of Liquids Apparatus work?

A: The apparatus uses two glass bulbs filled with different liquids connected to graduated glass tubes. When both bulbs are submerged in a heated water bath and warmed using an external heat source, the expansion of each liquid is observed and measured via the changes in liquid levels in the tubes.

Q: What types of liquids can be used with this apparatus?

A: It is suitable for common laboratory liquids such as water, alcohol, kerosene, and various oils. Users should make sure the liquid selected is thermally stable and does not react with glass or brass/copper components.

Q: When is this apparatus typically used in a laboratory setting?

A: The apparatus is ideal for physics education, especially in classroom demonstrations or laboratory experiments that illustrate the concept of thermal expansion in liquids. It is often used during lessons on heat, temperature, and material properties.

Q: Where should the Expansion Of Liquids Apparatus be set up for experiments?

A: Set up the apparatus on a stable, heat-resistant bench or table in a laboratory environment with adequate ventilation. Ensure a suitably safe and controlled space is available for using external heat sources like Bunsen burners.

Q: What is the process for measuring the expansion of liquids with this equipment?

A: Fill each glass bulb with a chosen liquid, place them in the water bath, and use the supplied thermometer to monitor temperature. Gradually heat the bath with an external source. As temperature increases, observe and record the rise in liquid levels in the graduated tubes for each substance.

Q: What are the main educational benefits of using this apparatus?

A: This apparatus provides students with a hands-on, visual understanding of thermal expansion in different liquids. It encourages inquiry-based learning, comparison of physical properties, and reinforces theoretical concepts in a practical way.
