Incubators Bacteriological

Get a Price/Quote

Incubators Bacteriological Specification

Automation Grade
Manual

Model No
BI-90

Feature
Double walled construction, glass wool insulation, adjustable shelves

Frequency
50 Hz

Capacity
90 L

Core Components
Heating element, thermostat, shelves

Voltage
230 V AC

Accuracy
1C

Measurement Range
Humidity not controlled

Temperature Range
5C above ambient to 60C

Power Source
Electric

Equipment Materials
Mild steel powder coated body, stainless steel inner chamber

Type
Bacteriological Incubator

Usage
Laboratory, Microbiology, Pathology

Display Type
Analog

Dimension (L*W*H)
505 x 415 x 720 mm

Weight
Approx. 40 kg

Door Type
Front opening with acrylic glass window

Heater Material
Nichrome wire

Inner Chamber
Stainless Steel 304 grade

Inner Dimensions
455 x 365 x 550 mm

Outside Finish
Epoxy powder coated

Safety Features
Over temperature protection

Air Circulation
Natural convection

Ambient Temperature Limit
Upto 40C

Thermostat Type
Capillary thermostat

Number of Shelves
2 or 3 (removable) depending on size

Heating Capacity
250 W

Insulation Thickness
50 mm glass wool

About Incubators Bacteriological

Incubators Bacteriological

Standard double wall fabrication. Inner chamber made out of richly anodized aluminium or highly polished stainless steel sheet and outer made out of thick mild steel sheet finished in white stoving enamel paint or mat finished pastle colour combinations.The gap is filled with special glass wool for temp. insulation. Double wall door with double window for observation in the chamber. Temperature range 5oC above ambient to 80oC + 2oC controlled by a thermostat. L- shaped thermometer is provided for taking temp. readings. Panel is provided with pilot lamps for mains & heaters, On-off switch, temp. Control knob etc. The equipment is workable on 220 V AC 50 Hz single phase. Heating is achieved from 3 sides. Perforated removable shelves also provided

Chamber size in mms. & Inches

300 x 300 x 300 (12" x 12" x 12")
350 x 350 x 350 (14" x 14" x 14")
400 x 400 x 400 (16" x 16" x 16")
450 x 450 x 450 (18" x 18" x 18")
600 x 450 x 450 (24" x 18" x 18")
600 x 600 x 600 (24" x 24" x 24")
900 x 600 x 450 (36" x 24" x 18")
900 x 600 x 600 (36 x24 x 24)
900 x 900 x 900 (36" x 36" x 36")

Optional :-

I) Air Circulating fan.

ii) Timer 0-24 hours.

iii) Imported Thermostat EGO/ JUMO German with the accuracy of 1C.

iv) Digital temp. Indicator- Cum Controller.

v) Digital Temp. Indicator

Precision and Versatility for Laboratory Needs

Designed to meet the demanding requirements of laboratories, this bacteriological incubator features a reliable heating system, accurate analog temperature control, and adjustable shelves to accommodate varied sample sizes. The double-walled insulation ensures thermal efficiency, while the stainless steel interior is easy to clean and corrosion-resistant.

Designed for Safety and User Convenience

Safety is prioritized through over-temperature protection, while observation is simple thanks to the acrylic glass window. The epoxy-coated exterior and robust construction contribute to long-term durability, making it an excellent investment for Indian distributors, exporters, and laboratory professionals.

FAQ's of Incubators Bacteriological:

Q: How does natural convection air circulation work in the BI-90 bacteriological incubator?

A: Natural convection in the BI-90 incubator allows heated air to circulates gently, providing even temperature distribution inside the chamber without the use of fans, making it ideal for sensitive microbiological applications.

Q: What benefits do the adjustable and removable shelves provide?

A: The incubator offers two or three removable shelves, depending on size, allowing flexible arrangement of samples and easy cleaning. This adaptability is especially useful when working with various sample containers or larger items.

Q: When should over-temperature protection be utilized?

A: Over-temperature protection is an automatic safety feature that activates if the chamber exceeds the set temperature, helping prevent damage to sensitive samples and equipment. It works continuously during all standard operations.

Q: Where can this incubator be used, and what applications is it best suited for?

A: The BI-90 is designed for laboratory, microbiology, and pathology environments. It is commonly used in educational institutions, research centers, hospitals, and industrial labs for cultivating bacteria and other microorganisms.

Q: What is the process for setting the desired temperature in the incubator?

A: Set the incubator's temperature using the analog capillary thermostat. Simply adjust the knob to your target temperature, within a range of 5C above ambient up to 60C. The analog display shows your set value for easy monitoring.

Q: How does the BI-90 ensure consistent and accurate heating?

A: The incubator uses a 250W nichrome wire heating element and 50mm glass wool insulation for efficient heat retention and distribution. Combined with a high-quality capillary thermostat, it maintains a stable temperature with 1C accuracy.
