Monsanto Type Tablet Hardness Tester

Get a Price/Quote

Monsanto Type Tablet Hardness Tester Specification

Response Time
Instantaneous (Manual)

Display Type
Analog Scale

Measuring Range
0-20 kgf

Specimen Size
Tablets up to 28 mm diameter

Test Range
0 to 20 kgf

Features
Portable, easy to operate, durable body, precise analog reading

Hardness
0-20 kgf

Equipment Type
Tablet Hardness Tester

Automation Grade
Manual

Power Supply
Not Required (Manual)

Resolution
0.1 kgf

Mounting Type
Bench top, hand-held

Accuracy
0.2 kgf

Number of Specimens
One tablet at a time

Application
Used to test the hardness of tablets in pharmaceutical laboratories

Humidity
15% to 90% RH (Recommended)

Temperature
10C to 40C (Recommended)

Usage
Laboratory testing of tablet hardness

Capacity
20 kgf

Machine Weight
1.25 kg (approx)

Test Speed
Manual Operation

Control Mode
Manual

Operating Principle
Measures pressure until the tablet breaks

Dimensions (L x W x H)
210 mm x 70 mm x 50 mm (approx)

Cleaning & Maintenance
Wipe clean with dry cloth after use

Body Material
Die-cast metal with chrome-plated finish

Scale Graduation
0.5 kgf

Compliance Standard
Meets IP/USP specifications

Force Measurement Type
Spring-based mechanical force

Tablet Placement Type
Horizontal

About Monsanto Type Tablet Hardness Tester

Monsanto Type Tablet Hardness Tester-KFW

A fairly handy instruments for taking quick readings for the hardness of tablets. It is made of brass turned parts, heavily chrome plated, the scale is 0 to 20 kg and the index mark and division is in 1 kg reading. Scale adjustable for zero setting as per size of the tablets.

Precise Manual Tablet Hardness Testing

Engineered for pharmaceutical labs, this Monsanto Type Tablet Hardness Tester delivers accurate readings between 0 and 20 kgf. Its analog scale provides clear measurement graduations at 0.5 kgf intervals. The spring-based force mechanism ensures reliable results for single tablets, supporting quality control routines without the need for electrical power.

Sturdy and Portable Construction

Featuring a die-cast metal body with a chrome-plated finish, this tester combines durability with portability. Weighing about 1.25 kg and designed for both bench-top and hand-held use, its easy to move between workstations. Its compact dimensions make storage and handling straightforward, ensuring it fits seamlessly into most laboratory setups.

Effortless Operation and Maintenance

Operation uses a simple manual process: place the tablet horizontally, apply force until it breaks, then note the reading. Maintenance is minimaljust wipe the tester clean with a dry cloth after each use. Its robust construction and manual design mean fewer breakdowns and low upkeep costs, enhancing overall laboratory efficiency.

FAQs of Monsanto Type Tablet Hardness Tester :

Q: How do I use the Monsanto Type Tablet Hardness Tester to measure tablet hardness?

A: To test tablet hardness, place a tablet horizontally in the device, manually apply force using the spring mechanism until the tablet fractures, and record the hardness value directly from the analog scale.

Q: What types and sizes of tablets can this tester accommodate?

A: The tester is suitable for tablets up to 28 mm in diameter and designed for single-tablet testing, making it ideal for a wide range of pharmaceutical tablet formats.

Q: When should this hardness tester be used in a laboratory setting?

A: Use this tester during quality control, formulation development, or research processes to verify that tablets meet required hardness, strength, and uniformity criteria as per IP/USP standards.

Q: Where is this tablet hardness tester typically installed or used?

A: Its compact and portable design allows for use either bench-top or hand-held in pharmaceutical laboratories, research institutions, and quality control environments.

Q: What benefits does the spring-based mechanical force measurement offer?

A: The spring-based mechanism provides instantaneous and precise manual measurement without requiring electricity, ensuring consistent readings and reliable performance over time.

Q: How do I clean and maintain the Monsanto Type Tablet Hardness Tester?

A: After each use, simply wipe the tester with a dry cloth to remove residual dust or particles. The robust die-cast metal construction and chrome-plated finish ensure durability and easy maintenance.

Q: What are the recommended operating conditions for this tester?

A: Operate the device in environments with 15% to 90% relative humidity and at temperatures ranging from 10C to 40C for optimal performance and longevity.
