Single Stage Quartz Distillation

Get a Price/Quote

Single Stage Quartz Distillation Specification

Frequency
50 Hz

Accuracy
Up to 99% Purity

Capacity
1-10 Liters/hr

Power Source
Electric

Temperature Range
Ambient to 100°C

Model No
QSD-1S

Feature
Low Maintenance, High Purity Output, Durable

Core Components
Quartz Boiler, Condenser, Stand, Power Cord

Automation Grade
Semi-Automatic

Measurement Range
1-10 L/hr

Voltage
220 V

Equipment Materials
Borosilicate Glass, High Purity Quartz

Type
Single Stage Quartz Distillation Unit

Usage
Laboratory Distillation, Purification of Water

Display Type
Analog

Dimension (L*W*H)
500 x 250 x 400 mm

Weight
Approx. 10 kg

Glassware Quality
Borosilicate and Pure Quartz Jointless Construction

Input Water Requirement
Tap Water

Service Support
Onsite Installation & Training

Heating Element Material
Nichrome Coil Encased in Quartz

Control Panel
Manual On/Off Switch, Indicator Light

Application
Analytical Chemistry, Medical Laboratories, Research Institutes

Cooling Arrangement
Integrated Water Cooled Condenser

Safety Features
Thermal Cut-Off, Overload Protection

Packaging
Shockproof Wooden Box

Distillation Output Quality
Pyrogen Free, Conductivity <1 µS/cm

Water Inlet/Outlet Connection
Standard Laboratory Hose Adapter

Ambient Operating Conditions
Temperature 10°C to 40°C, Humidity <80%

Mounting Type
Table Top

About Single Stage Quartz Distillation

Features :-

Replaceable Silica Heater : The horizontal quartz jacket is fitted with removable silica heater and screw threaded connectors for ease of cleaning.
Distillate temperature is approx. between 25° to 45° C which is ensured by an efficient condenser.
The stand is powder coated for rust free operation and lustrous appearance.
The unit automatically switches off if water level in the boiler falls below heater.
Cooling water from the condenser is re-circulated into the boiling chamber, hence saving energy.
Screw Threaded Connectors: These are provided for easy plumbing 8t Installation to avoid any glassware breakage during assembly.
Fuse is provided for safety in case of voltage fluctuation or short circuit.
Electrical Power: 220/240 V, 50/60Hz, Single Phase Supply.
Boiler is provided with Replaceable Constant Level Device for easy draining and cleaning of boiling chamber.

Unique Features :-

This model is equipped with in-built temperature switch to protect the Glass parts in case of water failure or overheating.

Additional Opetional Accessories :-

Gate Valve: Conserves cooling water wastage in case of power failure.
Flow Switch: In-built safety feature for the equipment unit shut off in case of cooling water failure.

Borosilicate Condenser :-

Model No.	SLSD-20B-HQ	SLSD-50B-HQ
Output Cap. (Approx.)	2 Itr/hr	5 Itr/hr
Power Rating (Total)	1.65 Kw	3.3 Kw
Cooling Water Consumption (Approx)	35 Itr/hr	70 Itr/hr

Quartz Condenser :-

Model No.	SLSD-20Q-HQ	SLSD-50Q-HQ
Output Cap. (Approx.)	2 Itr/hr	5 Itr/hr
Power Rating (Total)	1.65 Kw	3.3 Kw
Cooling Water Consumption (Approx.)	35 Itr/hr	70 Itr/hr

Advanced Quartz Distillation Technology

This distillation unit utilizes a nichrome coil housed in pure quartz, ensuring efficient heating while preventing contamination. The integrated water-cooled condenser maintains consistent operation and precise temperature control. A jointless construction with borosilicate and quartz promotes longevity and ease of maintenance, making it ideal for demanding laboratory environments.

Safety and User Convenience

The unit features essential safety systems such as thermal cut-off and overload protection for secure operation. Convenient mounting and a simple analog control panel with indicator lights support ease of use. The product is delivered in a shockproof wooden box, minimizing transport risk, and onsite installation with comprehensive training ensures smooth setup.

FAQs of Single Stage Quartz Distillation:

Q: How does the Single Stage Quartz Distillation Unit ensure high purity water output?

A: The unit combines a quartz boiler, borosilicate construction, and a nichrome coil heating element to prevent contamination. Its design includes a water-cooled condenser for efficient distillation, resulting in pyrogen-free water with conductivity below 1 S/cm.

Q: What type of water should be used as input for this distillation unit?

A: The device is optimized to purify ordinary tap water, transforming it into high-purity distilled water suitable for laboratory applications.

Q: When is onsite installation and training provided for this equipment?

A: Onsite installation and training are offered upon delivery, ensuring users are familiar with operation, maintenance, and safety protocols.

Q: Where is the Single Stage Quartz Distillation Unit typically used?

A: This equipment is commonly employed in analytical chemistry labs, medical laboratories, and research institutes where ultrapure water is required for experiments and testing.

Q: What is the process for operating the distillation unit?

A: Simply connect the water inlet and outlet to standard hose adapters, fill with tap water, and use the manual On/Off switch to start distillation. The indicator light signals operation while the integrated condenser facilitates efficient cooling.

Q: How does the thermal cut-off and overload protection enhance safety?

A: The thermal cut-off prevents overheating, while overload protection safeguards the system from electrical faults, ensuring secure and reliable performance during prolonged use.

Q: What are the benefits of using the QSD-1S model?

A: Users benefit from low maintenance, durable build quality, high purity water production (up to 99% accuracy), and consistent onsite service support, making it a valuable addition to any laboratory purification setup.
