Surgical Microscopes Direct Halogen

Get a Price/Quote

Surgical Microscopes Direct Halogen Specification

Diameter
Base Diameter Approx. 500 mm

Disposable Or Reusable
Reusable

Surface Finish
Smooth

Frequency
50 Hz

Finish Type
Powder Coated

Function
Magnification of Surgical Field

Display
No Digital Display

Instruments Type
Optical Microscope

Instrument
Microscope

Type
Direct Halogen

Material
Metal & Optical Glass

Condition
New

Portable
Yes

Rechargeable
No

Foldable
Yes

Sterilized
No

Waterproof
No

Use Type
Surgical

Operating Type
Manual

Power Source
Electric

Voltage
220 V AC

Dimension (L*W*H)
Approx. 600 mm x 400 mm x 1750 mm

Weight
Approx. 20 kg

Application
Microsurgery, ENT, Ophthalmic Surgeries

Type Of Equipment
Surgical Microscope

Size
Standard

About Surgical Microscopes Direct Halogen

With the help of our adroit professionals, we have been able to manufacture, export and supply an extensive assortment of highly reliable Surgical Microscopes Direct Halogen. Offered microscopes are manufactured with superior quality components utilizing advanced technology in conformity with predefined industry norms. Besides, these microscopes are used hospitals and clinics for viewing samples, cell structure, etc. In addition, clients can avail these Surgical Microscopes Direct Halogen in desired specifications and at affordable rates.

Features:

Fine focusing
High magnification
Compact built
Light in weight

Specifications:

Microscope Section

Binocular Tube

45 inclined (OPHTHALMIC)

Eyepieces

12.5x/ 10x/ 16mm Dioptric Adjustment

Magnification Changes

Built in Manual 3-Step Changer

Total Magnification

7.5x,12.5x,20x

Field of View

59mm, 37.8mm, 23.5mm

Objective Lens

F = 200(For General Micro-Surgical Fields)

Working Distance

200mm

Interpupillary Distance Adjustment

55mm to 75mm

Illumination Section

Type	:	Direct Halogen

Light Source	:	24V/250Watts Halogen lamp

Illumination Control	:	Continuous Adjustment

Field of illumination	:	70mm

Filter	:	Cobalt Blue, Red Free, Heat Absorbing

Stand Section

Type	:	Table Clamp

Vertical Movement Of Counterbalanced Arm	:	400 mm

General Information


Weight	:	50Kg.

Height	:	1550mm

Electrical Power	:	AC 220V, 240V, 50/60 Hz

Power Consumption	:	220 VA/110V

Optional Accessories

	Beam Splitter With CCD Camera Attachment

	CCD Camera


Optional accessories are listed as separate items in "Accessories" section under products, there brought separately.

Advanced Visualization for Precise Surgery

This surgical microscope offers magnification up to 20x with a high-quality 10x wide field eyepiece, allowing surgeons to closely examine fine anatomical details during complex procedures. The interchangeable 200 mm objective lens provides further adaptability, ensuring optimal viewing angles and clarity in every operation.

User-friendly, Flexible Design

Featuring an articulated, foldable arm and smooth castor wheels, the microscope is easy to position and move within the operating room. Adjustments such as interpupillary distance (5575 mm) and variable halogen lamp brightness enable comfortable, prolonged use. The powder-coated metal structure ensures lasting durability.

Comprehensive Support and Accessories

Each microscope comes with essential accessories including a dust cover, user manual, and standard cables. The equipment operates on standard 220V AC power and conforms to typical operating room environments. Maintenance is simple thanks to the reusable design, while a smooth surface finish allows for easy cleaning between uses.

FAQs of Surgical Microscopes Direct Halogen:

Q: How is the magnification range utilized during surgeries?

A: The microscope provides a magnification range from 3x to 20x, allowing surgeons to switch between low and high magnification for detailed inspection of tissues. This is particularly useful in microsurgery, ENT, and ophthalmic procedures where precise visualization is essential.

Q: What are the benefits of using direct halogen illumination?

A: Direct halogen illumination (12V/50W) produces a bright, natural white light, enhancing the visibility of the surgical field. The variable brightness knob allows users to adjust light intensity for minimal glare and maximum clarity during different procedures.

Q: Where can this surgical microscope be effectively used?

A: This microscope is suitable for use in operating rooms, clinics, and surgical centers, especially during microsurgery, ENT, and ophthalmic surgeries. Its portable, foldable design makes it easy to transport and position as needed.

Q: What is the process for adjusting the microscope for different users?

A: Users can easily adjust interpupillary distance (5575 mm) and select the appropriate magnification or objective lens based on the procedure. Coarse and fine focusing controls ensure sharp, clear images tailored to each users preference.

Q: How does the articulated foldable arm enhance usability?

A: The articulated foldable arm allows the microscope head to be positioned precisely over the surgical site, offering flexibility and stability. It can be folded away when not in use, saving space and facilitating easy movement within the operating room.

Q: Is this microscope suitable for long-term, repeated use?

A: Yes, the surgical microscope is made from high-quality metal and optical glass with a powder-coated finish. It is reusable, easy to clean, and designed for prolonged use in clinical environments. The included accessories support maintenance and longevity.
