Objective Microscope

Get a Price/Quote

Objective Microscope Specification

Features
Reliable achromatic optics, robust metal frame, ergonomic operation, smooth adjustment.

View Head
Monocular, inclined 45°

Focus System
Coarse and fine adjustment knobs; vertical movement of stage.

Spare Parts
Standard spare parts available: eyepiece, lamp, fuse.

Theory
Achromatic optical system offers enhanced clarity and contrast for specimen observation.

Drawtube
Standard monocular drawtube compatible with most laboratory setups.

Sensor
No integrated digital sensor; suitable for manual observation.

Resolution
Dependent on eyepiece and objective quality; up to 1000x effective resolution.

Interface
Mechanical interface with standard objective mounting (RMS compatible).

Focal Distance
Standard 45 mm (objective to sample).

Magnification
4X, 10X, 40X, 100X (oil) objective lenses included.

Dimensions
360 x 235 x 180 mm (L x W x H)

Focus Range
Coarse and fine adjustments available; total 30 mm travel.

Eyepieces
Widefield 10X eyepiece supplied.

Eyepiece Tube
Monocular eyepiece tube, 23.2 mm diameter.

Illumination
Halogen illuminator, 20W lamp for uniform lighting.

Coarse Adjustment Range
20 mm

Fine Adjustment Range
2 mm; precision fine focus knob.

Working Stage
Rectangular metallic, size 120 x 140 mm, with mechanical controls.

Image Format
None (no camera integration); visual observation only.

Interpupillary Distance
Fixed (single eyepiece); not adjustable.

Objective Achromatic
4/10/40/100X, DIN standard, achromatic glass lenses.

Condenser
Abbe condenser, NA 1.25, iris diaphragm.

Light Source
Built-in halogen lamp, 20W, adjustable brightness.

Revolving Nosepiece
Quadruple nosepiece with smooth rotation.

Weight
Approximate 6.2 kg.

Arm
Curved arm for easy handling and transport.

Dust Cover
Supplied for protection when not in use.

Stage Clips
Heavy-duty nickel plated dual clips for securing slides.

Voltage Input
220V AC, 50 Hz (standard plug).

Base
Sturdy cast iron base for vibration-free operation.

Diaphragm Type
Built-in iris diaphragm for light regulation.

Body Material
Metal alloy construction with chemical-resistant coating.

About Objective Microscope

For a limited time, secure this commanding Objective Microscopeengineered for prime laboratory results and cost-effective reliability. Its masterful build features a robust metal alloy body with chemical-resistant coating, heavy-duty stage clips, and a vibration-free cast iron base. Enjoy smooth, precise adjustments with the quadruple revolving nosepiece and dual focus system. Achromatic optical lenses ensure exceptional clarity up to 1000x magnification. This hot deal comes complete with halogen illumination, mechanical stage controls, and a protective dust cover, making it your best investment for advanced specimen analysis.

Application & Usage Method for Objective Microscope

Ideal for manual observation, the Objective Microscope employs achromatic objectives and a widefield 10X eyepiece for vivid, high-resolution specimen analysis. Select the proper objective lens4X, 10X, 40X, or 100X oilbased on your application needs. Simply secure your slide using sturdy dual clips, adjust illumination and focus, then observe with the monocular tube. The system suits varied laboratory setups and is especially effective for botanical, biological, and clinical plant applications.

Supply Ability & Sample Policy: Objective Microscope

We maintain a commanding stock of Objective Microscopes, ensuring rapid handover and competitive list pricing for distributors, exporters, traders, and laboratories. Sample units are available on request, with flexible sample policies designed to meet your prime needs. Simply inquire about the asking price for a demo unit; our team will efficiently arrange supply or dispatch samples throughout India. Spare parts such as eyepieces, lamps, and fuses are offered to support continued usage and uninterrupted laboratory performance.

FAQs of Objective Microscope:

Q: How does the Objective Microscope regulate light for precise observation?

A: The built-in iris diaphragm and Abbe condenser work together to modulate light intensity, providing users with superior control for detailed specimen viewing.

Q: What is the process for changing objective lenses on this microscope?

A: Rotate the smooth quadruple nosepiece to switch between 4X, 10X, 40X, and 100X oil immersion lenses seamlessly, depending on your required magnification.

Q: Where can I use this Objective Microscope effectively?

A: This microscope is ideal for laboratories, research institutions, schools, and clinical settings requiring reliable manual observation of biological or botanical samples.

Q: What is the benefit of the achromatic optical system?

A: The achromatic optical system offers enhanced clarity and contrast, minimizing color distortion and ensuring high-quality specimen imaging at various magnifications.

Q: When are sample units available for evaluation or purchase?

A: Sample units are available by request; please contact us with your requirements to discuss asking price and arrange swift handover for trial use.

Q: How robust is the Objective Microscope for daily use?

A: With a heavy-duty metal alloy body, cast iron base, and chemical-resistant coating, this microscope is designed for continuous, vibration-free, and durable operation in professional environments.
